Description
| MODEL | SBI 16*22 | SBI 18*24 |
| Max. paper size | 560*400mm | 620*450mm |
| Min. Paper size | 150*200mm | 620*450mm |
| Max printing area | 550*375mm | 600*440mm |
| Paper wait | 28-250g/m | 28-250g/m |
| Printing speed | 2000-7000sheet/hr | 2000-7000sheet/hr |
| Plate size | 560*420mm | 610*485mm |
| Ink roller | 14 pcs (3 ink from rollers) | 14 pcs (3 ink from rollers) |
| Total power | 1.3kw | 2.75KW |
| Paper feed mode | Suction cross feed | Cross feed with adhesive tape |
| Register device | Wheel- type side pull guide | Wheel- type side pull guide |
| Moistening mode | Water | water |
| Power supply | 220/50HZ | 220V/50HZ |
| Package size | 1800*1100*1350mm | 2050*115*1620mm |
| Total Weight | 750kg | 880kg |
